LiftingSafety 2 Point "Fixed Length" Lifting Beams. Central Fixed Top Ring & Suspension Eyes - Range from 1000kg to 6000kg (30 options)

LiftingSafety 2 Point "Fixed Length" Lifting Beams. Central Fixed Top Ring & Suspension Eyes - Range from 1000kg to 6000kg (30 options)

Fixed Single Lifting Beam.

Model:

TTP-3327

LiftingSafety 2 Point "Fixed Length" Lifting Beams. Central Fixed Top Ring & Suspension Eyes - Range from 1000kg to 6000kg (30 options)

main-product-image Tractel TOPAL PEF

LBF and LEF standard fixed single beam spreader* or LBM and LEM adjustable single beam spreader, for suspension from above via a central ring, fitted with two separate compensating beams for new lifting possibilities with tilting of the beam and/or the compensating beams.

  • Lifting with compensating beams providing symmetrical or asymmetrical traction, slanting inwards or outwards (max. angle 15°).
  • Lifting with the beam tilted at 6° from horizontal: - Vertical traction with symmetrical compensating beams. - Slanting traction with asymmetrical compensating beams.

Specification PEF

WLL (kg) L useful length (mm) Model Weight
1000 1000 LEF1-1000 26
2000 LEF1-2000 43
3000 LEF1-3000 59
4000 LEF1-4000 93
5000 LEF1-5000 167
2000 1000 LEF2-1000 26
2000 LEF2-2000 53
3000 LEF2-3000 106
4000 LEF2-4000 137
5000 LEF2-5000 198
3000 1000 LEF3-1000 33
2000 LEF3-2000 83
3000 LEF3-3000 113
4000 LEF3-4000 162
5000 LEF3-5000 240
4000 1000 LEF4-1000 52
2000 LEF4-2000 83
3000 LEF4-3000 140
4000 LEF4-4000 197
5000 LEF4-5000 295
5000 1000 LEF5-1000 68
2000 LEF5-2000 104
3000 LEF5-3000 165
4000 LEF5-4000 244
5000 LEF5-5000 348
6000 1000 LEF6-1000 69
2000 LEF6-2000 123
3000 LEF6-3000 194
4000 LEF6-4000 288
5000 LEF6-5000 392
Part N° Capacity (kg) Length (mm) Unit Price Quantity
3327-T27113 1000 1000 Quote Required
3327-T27114 1000 2000 Quote Required
3327-T27115 1000 3000 Quote Required
3327-T27116 1000 4000 Quote Required
3327-T27117 1000 5000 Quote Required

Description

+

LBF and LEF standard fixed single beam spreader* or LBM and LEM adjustable single beam spreader, for suspension from above via a central ring, fitted with two separate compensating beams for new lifting possibilities with tilting of the beam and/or the compensating beams.

  • Lifting with compensating beams providing symmetrical or asymmetrical traction, slanting inwards or outwards (max. angle 15°).
  • Lifting with the beam tilted at 6° from horizontal: - Vertical traction with symmetrical compensating beams. - Slanting traction with asymmetrical compensating beams.

Specification PEF

WLL (kg) L useful length (mm) Model Weight
1000 1000 LEF1-1000 26
2000 LEF1-2000 43
3000 LEF1-3000 59
4000 LEF1-4000 93
5000 LEF1-5000 167
2000 1000 LEF2-1000 26
2000 LEF2-2000 53
3000 LEF2-3000 106
4000 LEF2-4000 137
5000 LEF2-5000 198
3000 1000 LEF3-1000 33
2000 LEF3-2000 83
3000 LEF3-3000 113
4000 LEF3-4000 162
5000 LEF3-5000 240
4000 1000 LEF4-1000 52
2000 LEF4-2000 83
3000 LEF4-3000 140
4000 LEF4-4000 197
5000 LEF4-5000 295
5000 1000 LEF5-1000 68
2000 LEF5-2000 104
3000 LEF5-3000 165
4000 LEF5-4000 244
5000 LEF5-5000 348
6000 1000 LEF6-1000 69
2000 LEF6-2000 123
3000 LEF6-3000 194
4000 LEF6-4000 288
5000 LEF6-5000 392
