Ridgegear "RGL4/K12" Extension Strap to Allow Self-connection to Fall Arrest Blocks or Restaint Systems. 450mm Length

Ridgegear "RGL4/K12" Extension Strap to Allow Self-connection to Fall Arrest Blocks or Restaint Systems. 450mm Length

Webbing strop designed to be used as an extension strap fitted to the rear D-ring of a full body harness. For restraints or fall arrest block use only (not fall arrest lanyards).

Model:

RGL4/K12 / RES-3738

Description
Downloads

The extension strop/strap is designed to extend the attachment point of a full body safety harness into the field of vision, allowing operatives to self-connect to fall arrest blocks. The RGL4/K12 is not designed for and must not be used to extend a fall arrest lanyard. When being used with a lanyard, the RGL4/K12 must only be used in restraint scenarios.

A strong webbing is used for the strop with a break strength of 32kN, which provides greater strength, wear and shear resistance compared to other webbing.

It is also treated with a water repellent coating which should extend the life of this product.

Specifications

Accredited to: EN354:2010
Strap web material: 26mm RIDGE Protect anti-bacterial polyester*
Fittings: 1 x 10mm steel screwgate delta link (RGK12) at the harness connection end, with a choice of other compatible EN 362 connectors for the other end.
Max Arrest Force: Restraint only - Not to be used as fall arrest, unless used in conjunction with an EN360 fall arrest block
Length: 450mm, including connectors. If no connector is supplied for the anchorage end, an allowance of 100mm is made for the assumption that a 100mm karabiner is used as the connection means.

*14 times reduction in bacterial growth, according to ISO 20743:2013 contact with K.pneumoniae, commonly associated with healthcare infections such as E.coli.

Connector Options

Small Steel Karabiners and Connectors

Ridgegear "RGK1" Double Action Steel Screwgate Karabiner. 17mm Gate Opening

Steel manual screw gate connector with a 23kN minimum breaking strength.

Ridgegear "RGK2" Double Action Steel Twistlock Karabiner. 17mm Gate Opening

Steel automatic twist lock connector with a 25kN minimum breaking strength.

Ridgegear "RGK2P" Double Action Steel Twistlock Karabiner with Captive Pin. 17mm Gate Opening

Steel automatic twist lock connector with a 25kN minimum breaking strength.

Ridgegear "RGK3" Double Action Steel Twistlock Karabiner. 22mm Gate Opening

Steel automatic twist lock connector with a 50kN minimum breaking strength.

Ridgegear "RGK15" Triple Action Steel Karabiner with Captive Pin. 12mm Gate Opening

Steel automatic tri-action twist lock connector with a 40kN minimum breaking strength.

Ridgegear "RGK18" Steel Triple Action Karabiner with Captive Eye. 18mm Gate Opening

Steel automatic tri-action twist lock connector that is designed to be a permanent lanyard fixture. 45kN minimum breaking strength.

Ridgegear "RGK19" Steel Triple Action Karabiner with Captive Eye. 23mm Gate Opening

Steel automatic tri-action twist lock connector that is designed to be a permanent lanyard fixture. 45kN minimum breaking strength.

Small Aluminium Connectors and Karabiners

Ridgegear "RGK/1A" Aluminium Double Action Screwgate Karabiner. 19mm Gate Opening

Aluminium manual screw gate connector with a 24kN minimum breaking strength.

Ridgegear "RGK1/AT" Aluminium Triple Action Karabiner. 19mm Gate Opening

Aluminium automatic tri-action twist lock connector with a 24kN minimum breaking strength.

Ridgegear "RGK4" Double Action Aluminium Twistlock Karabiner. 22mm Gate Opening

Aluminium automatic twist lock connector with a 24kN minimum breaking strength.


Ridgegear "RGK7" Aluminium Screwgate HMS/Belay Karabiner. 26mm Gate Opening

Aluminium manual screw gate connector with wide load bearing design and side-swing gate. 22kN minimum breaking strength.


Ridgegear "RGK44" Swivel Aluminium Triple Action Snap Hook Karabiner. 22mm Gate Opening

Automatic aluminium tri-action swivel twist lock hook connector with a 30kN minimum breaking strength. Designed to be a permanent lanyard fixture.

Scaffold Hooks and Wide Jaw Karabiners

Ridgegear "RGK5" Large Double Action Steel Self-Locking Karabiner. 56mm Gate Opening

Scaffold hook style automatic twist lock steel connector with 30kN minimum breaking strength. Optional captivating pin supplied as standard.

Ridgegear "RGK6" Large Double Action Aluminium Self-Locking Karabiner. 53mm Gate Opening

Aluminium scaffold hook style automatic twist lock karabiner with a 23kN minimum break strength. Optional captivating pin supplied as standard.

Ridgegear "RGK11" Aluminium Double Action Self Locking Scaffold Hook. 60mm Gate Opening

Aluminium automatic double action scaff hook with captive eye. Designed to be a permanent lanyard fixture. 23kN minimum breaking strength.


Ridgegear "RGK11SL" Aluminium Double Action Self Locking Scaffold Hook. 55mm Gate Opening

Super lightweight aluminium automatic double action scaff hook with captive eye. Designed to be a permanent lanyard fixture. 25kN minimum breaking strength.

Ridgegear "RGK11/LSH" Aluminium Double Action Self Locking Scaffold Hook. 110mm Gate Opening

Aluminium automatic double action scaff hook with captive eye. Designed to be a permanent lanyard fixture. 27kN minimum breaking strength.

Ridgegear "RGK88" Aluminium Double Action Scaffold Hook. 62mm Gate Opening

Aluminium automatic double action scaff hook with captive eye. Designed to be a permanent lanyard fixture. 23kN minimum breaking strength.

Alloy and Steel Snap Hook Connectors

Ridgegear "RGK10" Steel Double Action Snap Hook. 19mm Gate Opening

Steel automatic snap hook with captive eye. Designed to be a permanent lanyard fixure. 23kN minimum breaking strength.

Ridgegear "RGK45" Steel Swivel Double Action Snap Hook. 21mm Gate Opening

Steel automatic snap hook with swivelling captive eye. Designed to be a permanent fixure. 23kN minimum breaking strength.

Ridgegear "RGK50" Aluminium and Steel Double Action Step Bolt Snap Hook. 18mm Gate Opening

Aluminium body, steel gate snaphook with captive eye for permanent connections. 23kN minimum breaking strength.

Semi Permanent Oval and Delta Link Connectors

Ridgegear "RGK12" Steel Delta Quick Link. 10mm Gate Opening

Triangular manual screwgate delta link, semi-permanent connector. 27kN minimum breaking strength.

Ridgegear "RGK20" Steel Screw Gate D Link. 10mm Gate Opening

Steel manual screwgate delta link, semi-permanent connector. 45kN minimum breaking strength.

RGL4/K12 Product Datasheet

(approx. 0.4Mb)

RGL4/K12 Declaration of Conformity

(approx. 0.1Mb)

User Instructions

(approx. 1.5Mb)

Connector, harness end

Connector, anchorage end
